Product Details:

Place of Origin: Hebei, China
Brand Name: Aier
Model Number: WA, WG, WY, WZ, WL

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD 100-5000
Packaging Details: iron frame, wooden case
Delivery Time: 20-40 DAYS
Payment Terms: T/T, L/C
Supply Ability: 200 PER MONTH
Detailed Product Description
Material: A05, A07, A33, A49, R08, R26, R33, OEM: Manufacture Accroding To Drawing
Application: Interchangable To Minng Slurry Pump, Slurry Pump, Sand Dreding Pump Parts Interchangable: Interchangable To Most Standard Slurry Pumps
Type: Horizontal Structure: One Stage
High Light:

Abrasive Slurry Pump

,

Sand Vacuum Pump

Centrifugal Mining Slurry Pump Spare Part wear resistant



Brief description of heavy anti-abrasive slurry pump

heavy abrasive slurry pump is designed and improved on some famous brand slurry pump.Now we can produce different size.The material of wet parts of this slurry pump is alloy or rubber.We choose the best material with high density to produce our slurry pump,so it is enough strong to serve for long time.



1. Slurry pump parts

Completely interchangeable with slurry pumps and  gravel pumps

For unlisted slurry pump parts, OEM service offered---Drawings needed.

- Impeller

- Metal Liner

- Rubber Liner

- Bearing Assembly

- Base

- Pump Volute;

- Cover Plate & Frame Plate

- Others



2. Materials

High chrome alloy: A05, A07, A33, A49, etc.

Natural rubber: R08, R26, R33, , etc.



3. OEM slurry pump part codes

Here we list some OEM part codes for reference:

Impeller: 127, 147, 145, etc., such as C2127, D3147, E4147, F6147, G8147, G10147, FAM1247...

Volute liner, C2110, D3110, E4110, F6110, G10110, G12110, ...



4. Frame & Bearing Assembly types

Types: B, C, D, E, F, R, X, ST, T, TU, CC, DD, EE, FF, etc.



Slurry Pump Part Material



Part Name Material Specification HRC Application OEM Code
Liners & Impeller Metal AB27: 23%-30% chrome white iron ≥56 Used for higher wear condition with pH between 5 and 12 A05
AB15: 14%-18% chrome white iron ≥59 Used for higher wear condition A07
AB29: 27%-29% chrome white iron 43 Used for lower pH condition especially for FGD. It also can be used for low-sour condition and desulfuration installation with pH no less than 4 A49
AB33: 33%-37% chrome white iron   It can transport oxygenated slurry with pH not be less than 1 such as phospor-plaster, nitric acid, vitriol, phosphate etc. A33
Rubber       R08
      R26
      R33

Expeller & expeller ring Metal B27: 23%-30% chrome white iron ≥56 Used for higher wear condition with pH between 5 and 12 A05
Grey iron     G01
Stuffing Box Metal AB27: 23%-30% chrome white iron ≥56 Used for higher wear condition with pH between 5 and 12 A05
Grey iron     G01
Frame/Cover plate, bearing house & base Metal Grey iron     G01
Ductile iron     D21
Shaft Metal Carbon steel     E05
Shaft sleeve, lantern ring/resctrictor, neck ring, gland bolt Stainless steel 4Cr13     C21
304 SS     C22
316 SS     C23
Joint rings & seals Rubber Butyl     S21
EPDM rubber     S01
Nitrile     S10
Hypalon     S31
Neoprene     S44/S42
Viton     S50
